Specifications
- Monitorized magnetic strip reader/ recorder ISO standard,
side and central strip versions
- Control/ validation of exit tickets and different types of
season cards
- Allow up to 4 periods of grace to be chosen for different
exits
- Inner container to collect exit tickets
- Control/ validation of season cards, full/ partial time,
residents, restricted areas cards as well as monetary value,
time limit and others system cards
- Anti-passback control on cards
- Accepts payment at exit with credit cards and automatically
issues a payment voucher (optional)
- Control of vehicle passage sequence, sending to the Central
Unit the ticket/ card code as to include it in the black list
- Barrier alarm control and management. Controls manual
barrier opening
- Self-adjusting electronic vehicle presence detector. Impedes
ticket or card validation by pedestrians
- User-oriented alphanumerical information display in two
languages. TFT monitor in option
- Date and time visualization on display while inactive
- Ethernet communications connection to the central unit.
Optional RS-422 connection
- Pocket terminal connection for maintenance processes
- Autonomous operation
- Electronically controlled internal heating/ ventilation
system
- Polyester powder painted and oven-dried steel housing
- Operating temperature: -20 ºC a +55 ºC
- Protected environment use (roofed)
- Power supply: 220 Vac. ± 10% 50 Hz (110 Vac. ± 10% 60 Hz.
optional)
- Maximum consumption 70 w (270w with heater option)
- Dimensions (in mm.): 1155 x 490 x 439
|
|
|
|
