Specifications
- Accept up to 14 different types of coins and returns change
with up to 4 different coin values
- 4 hoppers for coin recycling, storage and change return.
Each hopper can store up to 1000 coins approximately (depending
on type)
- Programmable automatic recharge of out-of-stock coins by
means of a safe container with an approximate 500 coins capacity
- Safety coin collection box
- Banknote acceptor for 4, 6 or 13 different notes types in
any of the 4 insertion directions with two deposits for
recycling, storage and change returns (optional) and a capacity
of 120 banknotes for cassete
- Safety banknote collection box (optional)
- Thermal printer (no printer ribbon required) for receipts,
payment vouchers, liquidation and accounts states
- Automatically issues liquidation voucher on withdrawal of
safety boxes (coins or notes). The voucher specifies the content
of box number of coins/ notes of each type and total
- Accepts payment with discount, money and time vouchers
- Accepts credit card payment
- Payment allowed for expended extra time by part-time season
holders
- Multilingual information display with 12” TFT monitor
- Motorized magnetic ISO lateral strip reader/ recorder
- Optional magnetic card reader/collector
- Ethernet communications connection to the central unit.
Optional RS-422 connection
- Pocket terminal connection for maintenance processes
- Powerless Operation: Incorporating a UPS to enable the
credit pay station to complete operations in progress in the
event of a power supply failure
- Polyester powder painted and oven-dried steel housing
- Operating temperature: -5 ºC a +40 ºC
- Protected environment use (roofed)
- Power supply: 220 Vac. ± 10% 50 Hz (110 Vac. ± 10% 60 Hz.
option)
- Maximum consumption: 200 w. (400 w. with heater option)
- Dimensions (in mm.): 1850 x 975 x 584
|
|
|
|
